YAKK Flameproof Electric Motor

YAKK Flameproof Electric Motor

  • YAKK Flameproof Electric Motor
  • YAKK Flameproof Electric Motor
YAKK Flameproof Electric Motor
Product Details:
Place of Origin: China
Brand Name: THMotor
Certification: CE
Model Number: T 7000
Payment & Shipping Terms:
Minimum Order Quantity: 1set
Price: USD 20000-100000
Packaging Details: Seaworthy packing
Delivery Time: 70DAYS
Supply Ability: 100SET/YEAR
Contact Now
Detailed Product Description
Product Name: YAKK Increased Safety High Voltage Flameproof Electric Motor Explosion-Proof​ Motor​ Power Range: 1000-12000kw
Voltage: 3kv-11kv Speed Range: 1000rpm-1500rpm
Poles: 4,6 Frequency: 50hz,60hz
Cooling Method: IC37,IC81W IP Rate: IP44,IP54,IP55
High Light:

YAKK Flameproof Electric Motor


YAKK Explosion Proof​ Motor​


Explosion Proof​ Motor​ H1120

YAKK Increased Safety High Voltage Flameproof Electric Motor Explosion-Proof​ Motor​



YAKK/YZYKK series increased safety type/positive pressure shell type compound explosion-proof high-voltage three-phase asynchronous motor (H355~H1120)
Frame No.: H355~H1120
Power range: 220kW~7100kW
Number of poles: 2~18
Rated voltage: 3000V, 6000V, 10000V
Explosion-proof mark: ExeIICT3 Gc+ExepzIICT3 Gc
Installation method: IMB3
Cooling method: IC611 (air-to-air cooling)
Working system: S1
Technical features: YAKK/YZYKK series is a new type of explosion-proof motor pioneered by our company. It adopts the combination of positive pressure shell type and increased safety type. The two types of explosion-proof work at the same time. When one type of explosion-proof type fails Another type of explosion protection can still ensure the safe operation of the equipment. This explosion-proof synchronous motor is provided with two sets of nameplates at the same time, namely the increased safety type explosion-proof motor nameplate and the positive pressure shell type explosion-proof motor nameplate. The explosion-proof type can work at the same time to improve the EPL (equipment protection level), or it can operate independently in any explosion-proof form. It can be made into first-level, second-level and third-level energy efficiency according to user requirements.
Application fields: This series of products are mainly suitable for fans, pumps, compressors, crushers, etc. in explosion-proof places where the explosion-proof area is "2" in industries such as petroleum, chemical industry, coal, power station, metallurgy, transportation, textile, medicine, and food processing. Machines, chip machine tools, transport machinery and other general mechanical equipment or other similar mechanical equipment.
